Genie Z-34/22 IC Diesel Knuckle Boom Hire Brisbane

Diesel Knuckle Boom

The Genie Z‑34/22 IC Diesel Knuckle Boom is a compact, rough-terrain articulating boom lift designed for elevated access in tight spaces and uneven ground. With 4WD capabilities, zero tail swing and no high-risk license required, this 34ft diesel knuckle boom is ideal for construction, facility maintenance, signage installation, and other demanding outdoor tasks. Ready for immediate hire in Brisbane, Gold Coast, and Ipswich, All Access Hire provides expertly maintained units that arrive fully compliant and site-ready.

Key Information

MAX WORKING HEIGHT 12.6 M
MAX PLATFORM HEIGHT 10.6 M
MAX HORIZONTAL REACH 6.8 M
UP AND OVER CLEARANCE 4.6 M
BASKET SIZE (LXW) 1.4x0.8 M
HEIGHT STOWED 2.06 M
WIDTH STOWED 1.85 M
LENGTH STOWED 5.66 M
TRANSPORT LENGTH 4.11 M
WEIGHT 5,100 KG
LIFT CAPACITY 227 KG
MAX. TYRE LOAD 2,404 KG
SPECIAL OPTIONS ANTI-CRUSH PROTECTION
NON MARKING TYRES
Productivity Features Self-leveling platform Proportional controls for smooth operation Zero tail swing and front arm swing for tight areas Tilt and descent alarms Drive speed: 4.8 km/h (stowed)
*The specifications showcased above are provided for reference and may vary with each machine model.
Not the right machine, we have more sizes available. View more...

Genie Z-34/22 IC for Tight Access & Outdoor Use

The Z‑34/22 IC is built to perform in rugged environments where maneuverability and height access are critical. Its compact chassis, zero tailswing, and exceptional up-and-over reach make it ideal for:

  • Outdoor construction and civil works
  • Maintenance of warehouses, factories, and infrastructure
  • Installation of lighting, signage, and utilities
  • Tree trimming and vegetation management
  • Event setup in outdoor venues or uneven surfaces

Common Uses for this Diesel Knuckle Boom

The Z-34/22 IC diesel knuckle boom is suited for diverse field conditions and industry applications:
Construction & Civil Works: Work at heights on unpaved or uneven surfaces
Facility Maintenance: Access external structures without damaging grounds
Telecommunications & Electrical: Install or maintain poles, towers, lines
Agriculture & Vegetation: Prune trees or maintain orchard infrastructure
Outdoor Events & Venues: Install lighting, signage, temporary structures
Compact enough for tight entry points, powerful enough for tough outdoor jobs.

Safety & Compliance: Built to Australian Standards

At All Access Hire, safety and compliance are integral to every hire. The Genie Z-34/22 IC meets or exceeds:

  • AS 1418.10 (Australian Standard for Elevating Work Platforms)
  • ANSI A92.5CSA B354.4, and CE compliance
  • Routine safety inspections before every hire
  • Fleet maintained to manufacturer standards
  • Emission-compliant diesel engines
  • Platform emergency descent system and alarms

Operators receive machines that pass all safety checks and are ready for use onsite. Backed by 10+ years of industry experience and thousands of successful hires.

Why hire with All Access Hire?

All Access Hire is a 100% Australian-owned access specialist, servicing construction, industrial and maintenance sectors across Queensland.

With over 40,000 successful hires, our reputation is built on:

  • Expert equipment advice
  • Fast turnaround
    Flexible hire terms
  • Reliable gear, always ready to work

Request a Quote Today

Need a reliable Z-34/22 IC fast? We’ll have it onsite and ready to go. Same-day delivery available in many cases Get expert advice to select the right boom for your jobsite, terrain and height – No high-risk license required for operation Request a quote now or contact our team to check availability near you.

Request a Quote

This field is for validation purposes and should be left unchanged.

Frequently Asked Questions (FAQs)

The Z-34/22 IC is ideal for outdoor construction, maintenance and access in tight or uneven spaces, where both vertical and horizontal reach are needed. Its 4WD and compact design make it a versatile option for many industries.
It offers a working height of 12.6 m, horizontal reach of 6.78 m, and a load capacity of 227 kg. It includes 4WD, 355° turntable rotation, proportional controls, and is suited for rough terrain.
No high-risk license is required due to its platform height under 11 m. However, a Yellow Card (EWPA) or formal training is strongly recommended to comply with Workplace Health & Safety (WHS) guidelines.
Yes, its compact stowed dimensions and zero tailswing allow it to work close to structures or inside large ventilated spaces. However, being diesel-powered, adequate ventilation must be ensured for indoor use.
Absolutely. We service Brisbane, Gold Coast, Ipswich and surrounding areas with fast, often same-day, delivery options.
